OPA740 Series
10 Watt Light Bar on
OptoTherm Linear Heat Spreader
OPA740 Series
?
?
10-1 watt LED on Linear substrate with 23° Lens
Mono-color per strip (Blue, Green, Red, Yellow, White)
?
?
?
?
Component beam angle 120°
Universal connector (Tyco 2-292173-2 mates with 173977-2)
Power connected to either end
RoHS Compliant
Product Photo Here
OPA740_ (23° Lens)
The OPA740 Series are designed for areas where lighting intensity and reliability are essential. The light beam
angle of 23° is ideal for illuminating areas close or a long distances from the device while requiring minimal space.
A High Performance Heat Spreader (HPHS) is used to ensure the best heat dissipation of any light assembly in
the industry.
OptoTherm is designed to be the optimum material for distribution of heat for high power devices.
For custom colors and design contact your OPTEK representative.
Electrical / Optical Characteristics: T A =25°C, I F =700mA
Part Number
OPA740Y23
OPA740B23
OPA740G23
OPA740R23
OPA740W23
Typical Forward Voltage (V)
12.5
18.0
18.0
12.5
18.0
Luminous Flux (lm)
297
76
408
221
408
Beam Angle
23°
Color
Yellow
Blue
Green
Red
White
Dominant Wavelength
587 nm
470 nm
530 nm
625 nm
6,500°K
+ Voltage
Ground
OPA740_
See OVSP_BCR4 for
component specifications
DO NOT LOOK DIRECTLY AT LED
WITH UNSHIELDED EYES OR
DAMAGE TO RETINA MAY
OCCUR.
RoHS
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. — 1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747 FAX: (972) 323-2396 visibleLED@optekinc.com www.optekinc.com
Issue A.2 09/08
Page 1 of 1
